Specifications

Processor AMD Ryzen Threadripper 2950X 16-cores (32 threads)

Base Clock Speed 3.5 GHz

Max Boost Speed 4.4 GHz

L3 Cache 32 MB

System Bus

Chipset Socket: TR4 Type: X399

Memory Slots 8 x DIMM 288-Pin

Memory Installed: 128 GB Capacity: 128 GB

Memory Type 8 x 16GB PC4-19200 2666 MHz DDR4 SDRAM

Graphics Type Dedicated

Graphics Card NVIDIA GeForce RTX 2080 Ti
CUDA cores: 4352
GPU memory: 11GB GDDR6 RAM
Memory interface: 352-bit
Memory bandwidth: 616 GB/s
Output: 7680 x 4320 (8K) @60Hz

Drives

Hard Drive Installed: 500GB Samsung 970 EVO NVMe M.2 Solid State Drive
1TB Samsung 970 Pro NVMe M.2 Solid State Drive

Optical Drive None

Drive Expansion 6 x 3.5" drive bays
2 x 2.5" drive bays
3 x M.2 SATA-III/PCIe Gen3 x4 connectors (2 x installed, 1 x available)

PCI Expansion 2 x PCI Express 3.0 x16 slots (PCIe x16 lanes)
2 x PCI Express 3.0 x16 slots (PCIe x8 lanes)
1 x PCI Express 3.0 x16 slot (PCIe x4 lanes)

Inputs/Outputs Ports 2x WiFi antenna ports (MMCX, 2T2R)
1 x PS/2 keyboard/mouse port
1 x USB Type-C™ port, with USB 3.1 Gen 2 support
1 x USB 3.1 Gen 2 Type-A port (red)
8 x USB 3.0
2 x RJ-45 LAN ports
1 x optical S/PDIF Out connector
5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In)

Display 3 x DisplayPort 1.4, 1 x HDMI 2.0b (NVIDIA GeForce RTX 2080 Ti), 1 x USB Type-C

Audio Realtek AC1220 7.1 channel HD audio codec

Flash Media Slot None

Communications 5. 1 x Thunderbolt™ 3 connector (USB Type-C™ port, with USB 3.1 Gen 2 support)

Network 2 x Intel® GbE LAN chips (10/100/1000 Mbit)

Wi-Fi Intel® Dual-band 2.4/5GHz, 802.11a/b/g/n/ac WiFi (up to 867 Mbps) Bluetooth BLUETOOTH 4.2, 4.1, BLE, 4.0, 3.0, 2.1+EDR

Keyboard & Mouse 9. 1 x optical S/PDIF Out connector

Keyboard Type: Full-Size
Features: Numeric Keypad

Mouse USB

General

Operating System Windows 10 Pro (64-bit)

Power Supply 1200 W

Dimensions (LxHxD) 18.3" L x 18.5" H x 8.3" D

Weight 30 lbs.

Warranty 3 years, parts and labor

Packaging Info

Package Weight 60 lbs.

Box Dimensions (LxWxH) 24" L x 24" W x 14" H

Included Items Keyboard & Mouse Logitech MK200 USB wired mouse and multimedia keyboard
